HOTBOX®

Part number: HOTBOX

Our top-of-the-line DI is an active direct box that operates with batteries or phantom power. Its super-clean front-end circuitry delivers extremely wide and flat frequency response and will reveal hidden harmonics from guitars and basses with high-output passive pickups.

* Type: Active

Features include:

* 1/4" parallel wired in/out jacks

* Ground Lift switch to help eliminate hum and buzz

* Input switch selects between OFF, ON or ON with 20 dB PAD engaged for connecting to strong line or speaker level signals.

* LED indicates "ON" status

Model # - HOTBOX

* Input Impedance: 1 Meg Ohms

* Frequency Response: 20Hz-150kHz ±3dB

* Residual Output Noise: -115dB

* Maximum Input Level: 15dBm - battery, 20dBm - 48V phantom. Add 20dBm with pad engaged

* Power Requirements: (2) 9V batteries or 48V phantom

* Battery Life: approximately 300 hours

* Current Draw: approximately 4.0mA DC
